56m
39m
VEHICLE SPECIFICATIONS
| Working Height 56m | Basket Size 1 x 3.7m |
| Outreach 39m | Safe Load 600KG |
| Travel Length 12m | Vehicle Weight 26t |
| Travel Height 3.8m | Cage Rotation 90°+90° |
| Travel Width 2.5m | Point Load 190kN/190kN |
JACKING
| Full | One Side | Straight Down | |
|---|---|---|---|
| Width | 9m | 6m | 3m |
Operated Hire Only
This machine is supplied with a fully qualified operator for the duration of your hire.
Not available for self-drive.
This machine is supplied with a fully qualified operator for the duration of your hire.
Not available for self-drive.
S56 | Bronto S56XR XJIB
56m
36m
VEHICLE SPECIFICATIONS
| Working Height 56m | Basket Size 1 x 3.7m |
| Outreach 36m | Safe Load 600KG |
| Travel Length 12m | Vehicle Weight 26t |
| Travel Height 4m | Cage Rotation 280°+280° |
| Travel Width 2.5m | Point Load 190kN/190kN |
JACKING
| Full | One Side | Straight Down | |
|---|---|---|---|
| Width | 9m | 6m | 3m |
Operated Hire Only
This machine is supplied with a fully qualified operator for the duration of your hire.
Not available for self-drive.
This machine is supplied with a fully qualified operator for the duration of your hire.
Not available for self-drive.
All specs serve as a guideline only and are correct at time of going live.
Smart reserves the right to change the specification without any prior notice.
